Hardware Installation and Reference Guide Product Overview
10
1. Grounding pole
2. Port mode switchover button
3. DC power socket
Heat Dissipation
The RG-ES110D-P adopts natural heat dissipation, thereby ensuring normal operation. You must maintain a minimum
clearance of 100 mm (3.94 in.) around the RG-ES110D-P. It is recommended that you clean the RG-ES110D-P once every
three months to avoid dust from blocking vents.
LEDs
The switch is powered off.
The switch is operational.
The port is not connected.
The port is connected at a rate of 10/100/1000
Mbps.
The port is receiving or sending traffic at a rate of
10/100/1000 Mbps.
PoE does not supply power.
