Ruijie Reyee RG-ES1 Series User Manual

ii
each power supply is equal to or less than 1.5 mA, and the total leakage current of the system is 30 mA. A leakage
protector with 30 mA rated action current supports less than ten power supplies (that is, action current of the leakage
protector/2/maximum leakage current of each power supply = 30/2/1.5 = 10). In other words, the leakage protector
with 30 mA rated action current supports no more than ten power supplies. In this case, the twenty power supplies
in the system require at least two leakage protectors with 30 mA rated action current and each leakage protector
supports ten power supplies. If power supplies in a system differ in models, the rated leakage action current of each
leakage protector divided by two is greater than the sum of maximum leakage current of all the power supplies. The
rated leakage non-action current of a leakage protector must be 50% of the leakage action current. The leakage
protector with 30 mA rated leakage action current is used as an example. The rated leakage non-action current
must be 15 mA. When the leakage current falls below 15 mA, the protector should not act. Otherwise, misoperation
may easily occur due to high sensitivity and thus the leakage protector trips, devices are powered off, and services
are interrupted.
To guarantee personal safety, the rated leakage action current of each leakage protector in the system must be
equal to or less than 30 mA (human body safety current is 30 mA). When twice of the total leakage current of the
system is greater than 30 mA, the system must be equipped with two or more leakage protectors.
For details of the leakage current value of each power supply model,
see Chapter 0
Contents
1 Product Overview ................................................................................................................................ 1
1.1 RG-ES106D-P ...................................................................................................................... 1
1.2 RG-ES126S-LP .................................................................................................................... 4
1.3 RG-ES110D-P ...................................................................................................................... 7
1.4 RG-ES118S-LP .................................................................................................................. 11
1.5 RG-ES116G........................................................................................................................ 14
1.6 RG-ES124GD ..................................................................................................................... 17
2 Preparation Before Installation.......................................................................................................... 21
2.1 Safety Suggestions ............................................................................................................. 21
2.1.1 Installation ................................................................................................................... 21
2.1.2 Movement .................................................................................................................... 21
2.1.3 Electricity ..................................................................................................................... 21
2.1.4 Static Discharge Damage Prevention ......................................................................... 22
2.1.5 Laser ............................................................................................................................ 22
2.2 Installation Site Requirements ............................................................................................ 22
2.2.1 Ventilation .................................................................................................................... 23
2.2.2 Temperature and Humidity.......................................................................................... 23
2.2.3 Cleanness ................................................................................................................... 23
2.2.4 Interference Resistance .............................................................................................. 24
2.2.5 Grounding .................................................................................................................... 24
2.2.6 Lightning Resistance ................................................................................................... 25
2.2.7 EMI .............................................................................................................................. 25
