Ruijie Reyee Series User Manual

Cookbook Advanced Solution Guide
81
d Enable Auth, set Auth IP Range 192.168.6.2-192.168.6.254 for authentication, and select a portal
template to be used. Then click Save to save all configurations.
Note
The IP addresses of the EG, switch, and AP need to be excluded; otherwise, the EG, switch, and AP
cannot access the Internet.
Configuration Verification
Choose Router > Advanced > LAN > Authentication > Cloud Auth. Check whether the configuration is
synchronized to the EG.

Ruijie Reyee Series Specifications

General

Model	Reyee Series
Category	Wireless Access Point
Wireless Standards	IEEE 802.11a/b/g/n/ac/ax
Frequency Bands	2.4 GHz, 5 GHz
Antenna Type	Internal or External
Ports	1 x Gigabit Ethernet
Power Supply	PoE or DC power adapter
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Management	Web-based
Security	WPA2
