Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
Blinking green
The PoE power exceeds the power of the entire
device (54 W). The new connected PD cannot be
powered up due to insufficient power. The
switching function is operational.
Solid green
The switch is operational.
RJ45 port PoE status
LED
1-8
Off
PoE is not enabled.
Solid green
PoE is enabled. The port is operational.
Blinking green
Indicates PoE overload.
1000Mbps RJ-45 port
status LED
1-9
Off
The port is not connected.
Solid green
The port is connected at 10/100/1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at
10/100/1000 Mbps.
1.2 RG-ES126G-P-L
Technical Specifications
Model
RG-ES126G-P-L
Optical Module
For details, see Appendix B.
The supported module type may change at any time. Consult us for the latest information.
SFP Port
Supports 1000Base-X modules.
Power Supply
 AC input
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 6A
Power cord requirement: 10A
EEE
Not supported
PoE
Supports PoE and PoE+.
Ports 1-24 are PoE/PoE+-capable with the maximum power output of 30W per port.
Ports 25 and 26 do not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 370W.
PoE Mode
Mode A (data pairs 1-2 and 3-6)
Power
Less than 25W with no PoE load
