Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
Less than 430W with PoE full load
Port Mode LED
Switchover Button
When the button is turned to the left position (Mode 1), the LED indicates the switching status
of the port: when the LED is solid green, it indicates that the link is up; when the LED blinks
green, data is being transmitted or received.
When the button is turned to the right position (Mode 2), the LED indicates the PoE status of
ports; when the LED is solid green, it indicates that the PoE-supported ports are supplying
power; when the LED blinks green, the power of the ports is overloaded.
Working Mode
Switchover Button
When the button is turned to the left position (flow control is enabled), all ports’ communication
is available and the flow control function is enabled on all ports.
When the button is turned to the middle position (VLAN isolation), ports 1-22 cannot
communicate with each other but ports 23-26 can communicate with each other; the flow
control is disabled on ports 23-26 but enabled on ports 1-22.
When the button is turned to the right position (flow control is disabled), all ports’
communication is available and the flow control function is disabled on all ports.
0℃ to 40℃ (32°F to 104°F)
-40℃ to 70℃ (-40°F to 158°F)
Supports adaptive speed adjustment. The fan stops running when the ambient temperature is
lower than 25°C and the PoE power is smaller than 185 W.
Accessing Optical
Module Information
440 mm x 292 mm x 43.6 mm
The RG-ES126G-P-L switch is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
Product Appearance
On the front panel, the RG-ES126G-P-L Ethernet switch provides twenty-four 10/100/1000Base-T Ethernet ports, and two
1000M SFP ports. On the back panel, it provides an AC power port.
Figure 1-4 Appearance of RG-ES126G-P-L
