Ruijie RG-S6150-X Series User Manual

Hardware Installation and Reference Guide Product Overview
13
System Status LED
(Front panel/Back
panel)
Status
Off
The system is not powered up.
Solid red
1. One of the modules of the system fails.
2. There are less than 3 fans.
3. The internal or partial temperature exceeds the
warning working temperature, and the switching
service resets.
Blinking green
The system is initializing.
Solid green
The system is operational.
Solid yellow
1. The temperature gets to the warning threshold.
2. Only 3 fans are in the position.
3. One of the dual powers is not connected with the
AC power cord.
Locator LED (Front
panel/Back panel)
ID
Off
Locator LED is controlled by CPLD. Locating,
function is disabled.
Solid blue
Device locating is enabled and the technical support
engineers enable or disable the locator LED
remotely.
MGMT Port LED
MGMT
Off
The port is not connected.
Green
The port is connected at 10/100/1000 Mbps.
Blinking
The port is transmitting or receiving data.
SFP28 Port LED
1F-24F
Off
The port is not connected.
Solid green
The port is connected at 1/10/25 Gbps.
Blinking green
The port is transmitting or receiving data at 1/10/25
Gbps.
QSFP28 Port LED
25F-32F
Off
The port is not connected.
Solid green
The port is connected at 40/100 Gbps.
Blinking green
The port is transmitting or receiving data at 40/100
Gbps.
Heat Dissipation
The working temperature of the RG-S6150-24VS8CQ-X switch is 0°C to 45°C, or 32°F to 113°F, and the heat
dissipation design needs to ensure the stability, safety and maintainability in such environment. The RG-S6150-
24VS8CQ-X adopts fan ventilation and forced convection to ensure the device can work normally in specified
environment. Dust the device every three months to avoid blocking the ventilation openings.
The RG-S6150-24VS8CQ-X supports M1EFAN II-F, and provides fan speed regulation, fan failure warning, and
fan hot swapping.

Ruijie RG-S6150-X Series Specifications

General

Brand	Ruijie
Model	RG-S6150-X Series
Category	Switch
Language	English
