Hardware Installation and Reference Guide Product Overview
4
Fan Module
M1EFAN II-F
Power Supply Slot
2 (support 1+1 redundancy)
Power Supply Module
RG-PA550I II-F
Note
The power supply module is not delivered with the switch. Please purchase the
module separately to ensure normal operation of the device.
Power Supply Input
AC input:
Rated voltage range: 100 V AC to 240
V AC
Maximum voltage range: 90 V AC to
264 V AC
Frequency: 50 Hz/60 Hz
Rated current: 3.5 A to 7.2 A
HVDC input:
Rated voltage: 240 V DC
Maximum voltage range: 192 V DC to 288
V DC
Rated current: 3.6 A
Power Consumption
Less than 300 W
Optical Module
Refer to Appendix 7.2
Note
The supported modules update at any time, contact Ruijie Networks for details.
Temperature Warning
Support temperature warning and over-temperature protection.
EMC Certification
GB/T 9254.1-2021
Safety Regulation
Compliance
GB 4943.1-2011
Working Temperature
C to 45°C (32°F to 113°F)
Storage Temperature
40°C to 70°C (40°F to 158°F)
Working Humidity
10% to 90% RH (non-condensing)
Weight
Net weight: 10 kg (20.05 lbs., with 4 fan modules and 2 power modules)
Dimensions
(W x D x H)
442 mm x 387 mm x 44 mm (17.40 in. x 15.24 in. x 1.73 in.), 1U
Caution
RG-S6150-48VS8CQ-X is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
