47
CAA66 Controller/Amplifier
Dimensions: 17"W x 11.5"D x 3.9"H (43 x 29.2 x 10 cm)
Weight: 17 lbs. 12.5 oz. (8 kg)
Power Supply: VAC 100-120 @3A or 220-240V @1.25A 50-60Hz
Fuse Rating: 110V input; F3.0A H 250V US and Canada
240V input; T1.25A H 250V Europe
Frequency Response: 20Hz-20kHz +0/-2.5dB
Watts per channel: 20W RMS into 8 ohms
Total Harmonic Distortion: <0.10%
Signal to Noise Ratio: >90.0 dB A-weighted / >88 dB unweighted
Audio Source Inputs: 6
Input Impedance: 50 kohms
Audio Zone Outputs: 6 speaker level (8 ohms)
2 line level
Max Source Audio Input: 2.2 Vrms
Zone Variable Line Audio Output: 2.5 Vrms
Zone Fixed Line Audio Output: 2.5 Vrms
Trigger Output: 12VDC 100mA Max
Trigger Input: 12VDC
TECHNICAL SPECIFICATIONS
