HEAVY DUTY
SOD CUTTER
LABELS
4163592
Rotate lever counter clockwise to
engage sodcutter blade drive.
Rotate lever clockwise to disengage
sodcutter blade drive.
GEAR CASE LUBRICATION:
See Operator Manual for proper uid,
checking, and lling procedures.
BLADE ADJUSTMENT
DEPTH OF CUT
1. LOOSEN UPPER RIGHT HAND LOCKING LEVER. TIP MACHINE FORWARD AND MOVE
CENTER DEPTH CONTROL LEVER TO DESIRED DEPTH. LOCK IN POSITION BY ROTATING
LOCKING LEVER CLOCKWISE.
2. LOOSEN DEPTH STOP LOCKING LEVER AT CENTER OF “H” FRAME. RAISE DEPTH STOP
UNTIL IT CONTACTS DEPTH CONTROL LEVER TUBE AND LOCK THERE SO BLADE CAN BE
RETURNED TO SAME POSITION AFTER EACH PASS.
HARD SOIL OPERATION
1. TIP BLADE FORWARD BY LOOSENING LOCKING LEVER (BLACK HANDLE FIGHT SIDE “H”
FRAME). PUSH “H” FRAME FORWARD AS REQUIRED.
2. TIGHTEN LOCKING LEVER AFTER ADJUSTMENT. 524366
