Ryobi TSS101L - Cutting Warped Material

31
OPERATION
wronG
WARNING:
To avoid a kickback and to avoid serious personal injury,
never position the concave edge of bowed or warped
material against the fence.
CLAMPING WIDE WORKPIECES
See Figure 39.
When cutting wide workpieces, such as 2 in. x 6 in., boards
should be clamped with a work clamp as shown in figure 39.
Fig. 39
wide
Board
Fig. 38
8
CUTTING WARPED MATERIAL
See Figures 37 - 38.
When cutting warped material, always make sure it is posi-
tioned on the miter table with the convex side against the
fence as shown in figure 37.
If the warped material is positioned the wrong way as shown
in figure 38, it will pinch the blade near the completion of
the cut.
Fig. 37
riGht
