PARTS LIST—SINGLE SLIDE DOOR ASSEMBLY BOM
27
SINGLE SLIDE DOOR ASSEMBLY BOM
ITEM
QTY.
PART #
DESCRIPTION
-
1
Consult Factory
Door Assy, 1 Way, LH, Turbo-Slide
Consult Factory
Door Assy, 1 Way, RH, Turbo-Slide (Shown)
1
1
P1091101-1
Head Assembly, 1 Way, Turbo-Slide, LH
P1091101-2
Head Assembly, 1 Way, Turbo-Slide, RH (Shown)
2
1
P1091112-1
Panel Assy, 1-Way, LH (Opens to Left) Turbo-Slide
2
1
P1091112-2
Panel Assy, 1-Way, RH (Opens to Right) Turbo-Slide (Shown)
3
1
P1091170-0
Stay Roller Assembly, Turbo-Slide
4
1
P1091180-X
Stay Roller Assembly, Universal Cam (RH or LH)
P1091170-0
Stay Roller Assembly, Turbo-Slide (Shown)
5
1
0799367
Photo Eye Assembly, Remote PE Receiver, LH
6
1
0799368
Photo Eye Assembly, Remote PE Emitter, RH
7
1
P1091198-2A
Bulb Seal Assembly, Heated, RH, Drive Side
P1091198-2B
Bulb Seal Assembly, Heated, RH, Non-Drive Side (Shown)
P1091198-2C
Bulb Seal Assembly, Non-Heated, RH
8
1
P1091198-1A
Bulb Seal Assembly, Heated, LH, Drive Side (Shown)
P1091198-1B
Bulb Seal Assembly, Heated, LH, Non-Drive Side
P1091198-1C
Bulb Seal Assembly, Unheated, LH
9
1
P1091199-0
Bulb Seal Assembly, Unheated, Top (Shown)
10
1
00142000
System 4 Control Panel
ALWAYS INCLUDE SERIAL NUMBER OF DOOR WHEN PLACING ORDER
Due to product enhancement, the actual parts on your door may be different from those shown in this manual.
