PARTS LIST—SINGLE SLIDE DOOR HEAD ASSEMBLY BOM
31
SINGLE SLIDE DOOR HEAD ASSEMBLY BOM
ITEM
QTY.
PART #
DESCRIPTION
-
1
P1091101-1
Single Slide Head Assembly, LH, Turbo-Slide (Shown)
P1091101-2
Single Slide Head Assembly, RH, Turbo-Slide
1
1
P1091120-2
Motor Assembly, Turbo-Slide, RH (Shown)
P1091120-1
Motor Assembly, Turbo-Slide, LH
2
1
P1091102-0
Header Hat Channel, 6M, Turbo-Slide
3
2
P1091103-0
3" J-Rail Track, Turbo-Slide
4
A/R
P1091105-0
J-Rail Track Bracket, Turbo-Slide
5
1
P1091130-0
Chain Release Assembly, Turbo-Slide
6
1
P1091140-0
Idler ASSY, Non-Drive Return, Turbo-Slide
7
2
P1091150-0
Assy, Door Swivel Hanger, Turbo-Slide
8
2
P1091160-0
Door Trolley Assembly, Turbo-Slide
9
1
P1091107-0
Single Slide Chain Tensioner, Turbo-Slide
10
2
P1091108-0
F71-R End Cap, Turbo-Slide
11
A/R
Consult Factory
5/16-18 x ¾” Clinch Bolt (Secure J-Rail to Track Brackets &
J-Rail Mounted Components)
12
A/R
R1091215-0
HLNSF, 5/16-18UNC, STL ZN
13
A/R
R1091209-0
3/8-16 x 1.00 SF Bolt (Secure J-Rail Brackets to Hat
Channel)
14
A/R
R1091208-0
3/8-16 x 2.00 SF Bolt (Secure Door Panels to Mounts and
Chain Release)
15
A/R
R1091216-0
3/8-16 SF Nut
16
2
R1091218-0
HHCS 3/4-10X2.5
17
2
R1091218-0
NUT, 3/4-10, HEX, JAM, ZN
18
1
P1091194-0
Drive Chain, 1-Way, Turbo Slide (Not Shown)
ALWAYS INCLUDE SERIAL NUMBER OF DOOR WHEN PLACING ORDER
Due to product enhancement, the actual parts on your door may be different from those shown in this manual.
