PARTS LISTBI-PARTING DOOR PANEL ASSEMBLY BOM
33
BI-PARTING DOOR PANEL ASSEMBLY BOM
ITEM
QTY.
PART #
DESCRIPTION
-
1
Consult Factory
Bi-Parting Door Assembly, Turbo-Slide (Consists of 1 each
Door Panel sub-assemblies items 1 & 2)
1
1
P1091110-1
Panel Assy, Bi-Parting LH, Turbo-Slide (Constructed of items
3, 4, 6, & 7)
2
1
P1091110-2
Panel Assy, Bi-Parting RH, Turbo-Slide (Constructed of items
3, 5, 6, & 7)
3
1
P1091111-0
Bi-Parting Door Panel, Turbo-Slide
4
1
P1091114-0
Assy, Seal, Bi-Part, Groove Section, Turbo-Slide
5
1
P1091115-0
Assy, Seal, Bi-Part, Tongue Section, Turbo-Slide
6
2
P1091195-0A
Panel Bottom Seal, BiPart, R17, Turbo-Slide
P1091195-0B
Panel Bottom Seal, BiPart, R25, Turbo-Slide
7
A/R
P1091118-0
Manual Release Handle, Turbo-Slide (Standard qty = 1)
ALWAYS INCLUDE SERIAL NUMBER OF DOOR WHEN PLACING ORDER
Due to product enhancement, the actual parts on your door may be different from those shown in this manual.
