PARTS LIST—BI-PARTING DOOR HEAD ASSEMBLY BOM
29
BI-PARTING DOOR HEAD ASSEMBLY BOM
ITEM
QTY.
PART #
DESCRIPTION
-
1
P1091100-1
Head Assy, Bi-Parting, Turbo-Slide, LH
P1091100-2
Head Assy, Bi-Parting, Turbo-Slide, RH (Shown)
1
1
P1091120-2
Motor Assembly, Turbo-Slide, RH (Shown)
P1091120-1
Motor Assembly, Turbo-Slide, LH
2
1
P1091102-0
Header Hat Channel, 6M, Turbo-Slide
3
4
P1091103-0
3" J-Rail Track, Turbo-Slide
4
A/R
P1091105-0
J-Rail Track Bracket, Turbo-Slide
5
2
P1091130-0
Chain Release Assembly, Turbo-Slide
6
1
P1091106-0
Chain Reverser Assembly (Idler), Turbo-Slide
7
1
P1091140-0
Idler Assy, Non-Drive Return, Turbo-Slide
8
4
P1091150-0
Assy, Door Swivel Hanger, Turbo-Slide
9
4
P1091160-0
Door Trolley Assembly, Turbo-Slide
10
1
P1091107-0
Single Slide Chain Tensioner, Turbo-Slide
11
2
P1091108-0
F71-R End Cap, Turbo-Slide
12
A/R
Consult Factory
5/16-18 x ¾” Clinch Bolt (Secure J-Rail to Track Brackets &
J-Rail Mounted Components)
13
A/R
R1091215-0
HLNSF, 5/16-18UNC, STL ZN
14
A/R
R1091209-0
3/8-16 x 1.00 SF Bolt (Secure J-Rail Brackets to Hat
Channel)
15
A/R
R1091208-0
3/8-16 x 2.00 SF Bolt (Secure Door Panels to Mounts and
Chain Release)
16
A/R
R1091216-0
3/8-16 SF Nut
17
4
R1091218-0
HHCS 3/4-10X2.5
18
4
R1091218-0
NUT, 3/4-10, HEX, JAM, ZN
19
1
P1091193-0
Drive Chain, Turbo Slide (Not Shown)
ALWAYS INCLUDE SERIAL NUMBER OF DOOR WHEN PLACING ORDER
Due to product enhancement, the actual parts on your door may be different from those shown in this manual.
