Vehicle Care 10-39
Low-Beam Headlamps/Daytime
Running Lamps (DRL) (Base)
1. Remove the protective cap from
the back of the headlamp
assembly.
2. Disconnect the electrical
connector.
3. Remove the bulb socket from
the headlamp assembly.
4. Replace the bulb in the bulb
socket.
5. Install the bulb socket in the
headlamp assembly.
6. Connect the electrical connector.
7. Install the protective cap in the
back of the headlamp assembly.
High-Beam Headlamps (Base)
1. Disconnect the electrical
connector for the low-beam/
Daytime Running Lamp (DRL)
from the back of the headlamp
assembly.
2. Remove the bulb socket from
the headlamp assembly.
3. Replace the bulb in the bulb
socket.
4. Install the bulb socket in the
headlamp assembly.
5. Connect the electrical connector.
High/Low‐Beam Headlamps
(Uplevel)
The high/low‐beam headlamps on
the uplevel are High Intensity
Discharge (HID) and should be
replaced at the dealer.
Daytime Running Lamp (DRL)
(Uplevel)
To replace the Daytime
Running Lamp:
1. Disconnect the electrical
connector for the DRL bulb
replacement from the back of the
headlamp assembly.
2. Remove the DRL bulb socket
from the headlamp assembly.
3. Replace the bulb in the bulb
socket.
4. Install the bulb socket in the
headlamp assembly.
5. Connect the electrical connector.
