10-46 Vehicle Care
J-Case
Fuses
Usage
26
Rear Electrical
Center 2
27 Not Used
41 Cooling Fan 2 (LF1)
42 Starter
43 Not Used
44 Not Used
45 Cooling Fan 1 (LF1)
59
Secondary
AIR Pump
Mini Fuses Usage
1
Engine Control
Module Battery
2
Transmission
Control Module
Battery
3
Mass Air Flow
Sensor
4 Afterboil Pump
Mini Fuses Usage
5
Engine Control
Module Run Crank
7
Post–Catalytic
Converter O2
Sensor
8
Pre–Catalytic
Converter O2
Sensor
9
Engine Control
Module Powertrain
10 Fuel Injectors–Even
11 Fuel Injectors-Odd
13 Washer
16
Instrument Panel
Cluster/Malfunction
Indicator Lamp/
Ignition
17 Air Quality Sensor
18 Headlamp Washer
19
Transmission
Control Module Run
Crank
Mini Fuses Usage
20
Rear Electrical
Center Run Crank
23 Heater Motor
30 Switch Back Light
32
Battery Sense
(Regulated Voltage
Control)
33
Adaptive Forward
Lighting/Adaptive
Headlamp Leveling
Module
34
Body Control
Module 7
35
Electronic Brake
Control Module
46
Low-Beam
Headlamp‐Right
47
Low-Beam
Headlamp‐Left
50 Front Fog Lamps
51 Horn
