Product Overview
The MorphoAccess
®
SIGMA Lite Series
terminal has a simple and ergonomic man-
machine interface designed for access
control and Time & Attendance, with
fingerprint recognition, contactless card
authentication and PIN authentication
options.
(for configuration with a
USB mass storage key)
Power consumption shall
not exceed 200mA
MorphoAccess® SIGMA Lite Series –
Quick User Guide - 2015_2000005700-V4
Optical biometrical sensor
Status LED
Optional 2,8“
touchscreen LCD
(SIGMA Lite+)
Embedded web server
(configuration & enrolment)
Status LED
HID® iCLASS™ 13,56MHz (SIGMA … ICLASS)
Or MIFARE™ DESFire ™ 13,56MHz (SIGMA .. MULTI)
Or HID® Prox ® 125kHz (SIGMA .. PROX)
Optional RF
Card reader
Large User
feedback
LED panel
(SIGMA Lite)
USB host port
Buzzer
Optional
sensor
protection cap
