2 - Connecting the SAGEM F@st
TM
800 / 840
SAGEM F@st™ 800 / 840 (PPP) User Guide - 288 047 975-03
Page 2-2 Sagem Communication document. Reproduction and disclosure prohibited
2.1 Connecting the SAGEM F@st™ 800 / 840 modem
CAUTION
Do not connect your modem to your computer with the USB cable before you have installed the
drivers from the CD-ROM.
Only use the ADSL line cable supplied with your equipment for the connection to the remote
network :
RJ11 / RJ11 for the SAGEM F@st
TM
800 (PSTN),
RJ45 / RJ11 for the SAGEM F@st
TM
840 (ISDN).
2.1.1 Connecting the SAGEM F@st™ 800
The connections must be made in the following order:
1
Connect one end of the line cable to the telephone socket
2 Connect the other end of the line cable to the LINE connector on the modem
If using an input splitter or microfilters, their outputs must also be fitted with RJ11 connectors. If
not, contact your Operator for an adapter or a specific cable.
3
Connect the "flat" connector at one end of the USB cable to one of the type
A USB ports on the computer (or on the HUB if appropriate), marked with
the following symbol:
4 Connect the "square" connector at the other end of the USB cable to the USB connector
on the rear panel of the modem, when prompted by the driver installation software.
