4 - Installation in Mac OS X
SAGEM F@st™ 800 / 840 (PPP) User Guide - 288 047 975-03
Sagem Communication document. Reproduction and disclosure prohibited Page 4-15
"Packets" area
Field Description
Packets Rx
Indicates the number of AAL5 packets received since the connection
was set up
Packets Tx
Indicates the number of AAL5 packets transmitted since the
connection was set up
Dropped
Indicates the number of AAL5 packets lost since the connection was
set up
4.3.2.3 "Configuration" screen
"Configuration" area
Field Description
ATM Channel VPI Displays the value 8 by default. This field can be used to enter a
VPI value between 0 and 255
ATM Channel VCI Displays the value 35 by default. This field can be used to enter a
VCI value between 0 and 65535
Encapsulation Type PPPoA LLC
PPPoA VCMUX (Default value)
PPPoE LLC
PPPoE VCMUX
ADSL Standard ANSI TI.413
G.DMT
G.992.3
Multi Standard (Default value)
