7.2. Picture adjustment
7.2.1. HD outputs
If you have connected your terminal to an "HD ready" flat screen with a YUV, HDMI or DVI input, you should
set "HD outputs activation" to "Yes".
• Select the required resolution: 1080i or 720p.
• "Make sure that the chosen screen format is
16/9.
• Choose the AUX scart video standard (PAL or
S-Video).
• Note that the video output on the AUX scart is
not in HD quality but in SD and the 16/9 format
of the HD video will be delivered in 4/3 letter
box format.
• "If the terminal's HD outputs are used (YUV or
HDMI) the TV scart only outputs PAL video
(RGB cut).
7.2.2. SD output
If you have not connected your terminal to an "HD ready" flat screen, but to a standard 16/9 or 4/3 television,
you should set the "HD outputs activation" option to "No".
The YUV and HDMI outputs on your terminal will then output no video signal.
• Choose the format of your standard TV: 4/3 or
16/9.
• If you have a 4/3 TV, select the "Letter box"
option in other words a 16/9 picture in a 4/3
screen, or the "pan and scan" option, in other
words the centre of a 16/9 image in a 4/3
screen.
• Choose the TV scart video: PAL or RGB (better
quality).
• Choose the AUX scart video: PAL or S-video
(better quality).
VIDEO SETTINGS
HD outputs activation
HD outputs resolution
TV screen format
video resizing
AUX scart
Yes No
1080i 720p
4/3 16/9
letter box pan & scan
PAL S-VIDEO
CANCELDEFAULT VALUES OK
VIDEO SETTINGS
HD outputs activation
TV screen format
video resizing
TV scart
Yes No
4/3 16/9
letter box pan & scan
PAL RGB
CANCELDEFAULT VALUES OK
AUX scart PAL S-VIDEO
