DIGITAL TERMINAL USER MANUAL
20
11. TECHNICAL CHARACTERISTICS
Transmission standards
DVB-T, MPEG-2, MEPG-4
TERRESTRIAL FRONT END
TERRESTRIAL RF INPUT
Input freq. range: UHF 470-862 MHz (8
MHz BW) - VHF 174-222 MHz (7/8 MHz
BW)
Loop through output frequency
Range: 47- 862 MHz
COFDM bandwidth: 7MHz & 8MHz
RF input level: -90 to -20 dBm
RF impedance: 75 Ohm
Tuning step: 166.66KHz
TERRESTRIAL DEMODULATOR
DVBT
COFDM mode: 2k /8k, SFN supported
Modulation: QPSK, 16-QAM, 64-QAM
VIDEO DECODER
MPEG2
standard MPEG-2 MP@HL for 50Hz
Input rates (max) 80 Mbit/s at ship input
MPEG-4 PART 10/H.264
MPEG-4 AVC HP@L4 (HD) for 50Hz
Input rates (max): 20 Mbit/s for HP@L4
MPEG-4 AVC HP@L3 (SD)
Input rates (max): 10 Mbit/s for HP@L3
AUDIO DECODER
MPEG-1/MPEG2 layer I
MPEG-1/MPEG2 Layer II (Musicam
Audio)(2.0)
DOLBY AC3 Loop through
Audio decoder, sampling rates 32, 44.1 or
48kHz
OUTPUT RESOLUTION / FORMAT
HD
: 1280x720 @ 50Hz progressive, or
1920x1080 @ 50Hz interlaced - Aspect
ratio 16/9
SD
: Aspect Ratio: 4:3 and 16:9
Conversion: Pan and Scan, Letter box
Scaling: SD > HD
SD INPUT / OUTPUT
TV SCART
RGB out, CVBS, Audio R/L
AUX SCART
CVBS, S-video, RGB in, Audio R/L
HD OUTPUT
RCA
Y, Pb, Pr, audio R/L
HDMI with HDCP
AUDIO OUTPUT
HiFi audio output
mono stereo in case of MPEG1 layer II,
Electrical S/PDIF
two channel PCM in case of MPEG1-
layerII, Originally received beatstream in
case of AC3
CONDITIONAL ACCESS*
1 x ISO/IEC 7816 Smart Card Reader
FRONT PANEL
4 digits amber colour display
Indicator: 1 dual colour led
IR sensor: 38 KHz
3 buttons
1 smart card reader
REAR PANEL
1 x IEC169-2 female (terrestrial in)
1 x IEC169-2 male (terrestrial out)
2 x SCART (TV, AUX)
1 x HDMI
6 x RCA (YPrPb, Stereo L/R, S/PDIF)
POWER SUPPLY
Mains supply voltage 220-240 V ~50 Hz
Power Consumption max: 25W
*not available, free to air DTT only.
