- 45 -
14. SPECIFICATIONS
Transmission Standards
DVB-T, MPEG 2, OFDM
Tuner (2 with internal splitter)
RF Input
Input Connector: IEC 169-2 female
RF input frequency range:
UHF 470-862 MHz (8 MHz BW)
VHF 174-222 MHz (7 and 8 MHz
BW)
RF input level: -90 to -20 dBm
Input impedance: 75 Ohms
COFDM bandwith: 8 MHz
Tuning step: 166.66 Khz
RF output
Output connector: IEC 169-2 male
RF bypass: 47-862 MHz
Demodulator
COFDM modes supported: 2 k/8 K
Support: SFN
Modulation: QPSK, 16-QAM, 64-
QAM
Code rate: 1/2 to 7/8
Mode: Non-hierarchical
Guard interval: 1/4, 1/8, 1/16, 1/32
Hard disk (80 to 400GB)
Capacity of recording:
DTR 64XXX/DTR 67XXX (where
XXX corresponds to the capacity in
GB of the disk). One hour of
recording requires on average
between 2 and 2.5 GB of space on
the hard disk drive.
1/16 of the disk capacity is allocated
for photo and audio files.
Video receiver
MPEG-2 SD(ISO/IEC 13818-2)
Profile and level supported:
MP@ ML
Input rates: 1.5 to 15 Mbit/s
Aspect ratios: 4:3 and 16:9
Video resolutions:
720x576, 704x576, 544x576,
480x576, 352x576, 352x288
Conversions: Pan and Scan,
Letterbox
Audio receiver
ISO/IEC13818-3 standard
compliant.
MPEG-Layer I and II (Musicam
Audio )
Mode: Mono, Stereo
Sampling frequencies:
32/44, 1/48 Khz
A/V Input/Output
TV SCART
RGB, PAL, Audio stereo Outputs
AUX SCART
RGB input, PAL, S-Video output
YPrPb output
Analog video (in this case,no RGB
available TV scart).
720x576@50Hz interlaced
Audio Digital output
PCM Stereo or AC3 via IEC958
optical and RCA
HDMI output (model DTR6700T only)
Version 1.2 without HDCP
SD video:
720x576@50Hz interlaced
720x576@50Hz progressive
Scaling SD>HD :
1280x720@50Hz progressive
or
1920x1080@50Hz interlaced
Aspect ratio : 4:3 and 16:9
Audio : Two channels PCM in case
of MPEG1-Layer II or dolby digital
(AC3).
Supported multimedia files
Audio files: mp3, Mp3, MP3 (in CBR
and VBR encoding).
Photo files in standard jpeg format
(non progressive). Supported
extensions: jpeg, Jpeg, JPEG, jpg,
Jpg, JPG.
Maximum photo size: 24 Mpixels.
USB Connection
Port: Master USB 2.0
Supported device: mass storage
device formatted only in FAT32 with
only 1 logical partition.
Maximum connections of 2 USB
devices using a Hub.
External power supply
AC: 220-240 V ~50 Hz
Output: 12 V DC 2A
Max power consumption: 18 W
(standby 5 W, 2 W for eco model)
Indoor antenna power supply
Output: +5 V DC, 50mA max, +5 V
on the core of the cable
Front panel
1 seven-segment amber display
IR sensor: 38 kHz
3 buttons (P+,P-,ON/STANBY)
1 USB connector
Physical Specifications
Receiver:
Size (lxdxh): 310x199x46 mm
Weight: ~1.75 kg
Operating temperature: +5°C to
+40°
Storage temperature: -25°C to
+65°C
Accessories
Remote control unit range: 7 m
Batteries: 2 X 1.5 V (AAA type)
1 Scart lead
External AC/DC Adapter with
power cord
DTR67_ EN.book Page 45 Mardi, 20. avril 2010 2:46 14
