Metrological menu
The screens listed below are replaced on each short push on the button. Once at the last screen, it
moves back to first screen.
If the user does a long push on the front button, the display state machine switches to the next menus.
The triangle at the bottom of the display indicates which other menu is active , moving from left to
right. In Metrological menu, no triangle are active.
On special certification screen (like Test selection ), user must double press quickly on the button in
order to enter in selection mode and the screen starts to blink. Then, with a simple press/release, the
screen toggles between ‘YES’ or ‘no’. Validation is done by a quick double press. The screen stops
blinking and presents the value selected .
Table 6: Metrological menu screen
History menu
The history menu is a summary over time of the measurement.
Table 7: History menu screen
