5 Unpacking and inspection
Saimo Model 6101 integrator has been properly packaged for shipment and storage.
Optional equipment unpacking, please see annex for instruction.
Inspect all packages for damage before opening as oftentimes the carrier may be
responsible for shipping damage. Optional equipment inspection, see annex for
instruction please.
1.
1.
1.
1. 6
6
6
6 Storage
6101 integrator can be safely stored with cover latches secured and hole plugs
installed, between -40
℃—
+70
℃
. The units should be protected against moisture.
1.
1.
1.
1. 7
7
7
7 Symbol
Symbol
Symbol
Symbol
Symbol Instruction
Instruction
Instruction
Instruction
Symbol Description
AC
Grounding end
Shielded grounding
Warn, power
Warn
1.8
1.8
1.8
1.8 Hardware
Hardware
Hardware
Hardware instruction
instruction
instruction
instruction
1.8.1
1.8.1
1.8.1
1.8.1 Housing
Housing
Housing
Housing
See Chapter 2 for Installation dimension drawing (Figure 2-1, 2-3, 2-4)
1.8.2
1.8.2
1.8.2
1.8.2 Ambient Condition
· Location: Indoor or outdoor, as close as possible to the load cells, free from
damp and dust.
· Temperature:
Storage temperature : -40~+70 º C
Operati ng temperature -10~+50 º C
· Max imum Relative Humidity: 95%
· Pollution Degree: pollution II
· Elevation: 2000m
1.8.3
1.8.3
1.8.3
1.8.3 Power
Power
Power
Power Requirements
Requirements
Requirements
Requirements
· 110/220/240 VAC ， +10%,-15%;50/60Hz,select via switch on mainboard
· Fuse: 0.5A Φ 5mmX20mm
· EMI / RFI filter
