Press ↑↓ key to select submenu, use numeric key to input the value desired.
Press “ PAGE DOWN ” soft key, the first page of the Calibration Data Menu is displayed.
Refer to below table for setup range
：
Description Range
Simulated Cal. R-cal., Test weight, Test chain
Resistor 0 1000000
weights 0 1000000
Chain 0 1000000
Resistance is as per actual resistance used. (R3 and R3 ’ in AD board)
Press “ PAGE DOWN ” soft key, the second page of the Calibration Data Menu is displayed.
Refer to below table for setup range:
Description Range
Constant -1000 1000000
Material factor 0 1000000
Zero track 0 1000000
2006-3-21 12:00:00 Scale#1
CALIBRATION DATA 1
Simulated ： [ ELECTRIC ]
Resistor ： [ 165000Ohms ]
Weights ： [ 100kg ]
Chain ： [ 100kg/m ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
2006-3-21 12:00:00 Scale#1
CALIBRATION DATA 2
Constant ： [ 800 ]
Matl. Factor
：
[ 2% ]
Zero Track ： [ 3% ]
Zero Range ： [ 4% ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
