44
Pressing “ PAGE DOWN ” soft key enters the sixth page of the I/O Definition Menu.
Move the cursor to “ Delay ” with Up/Down scroll keys and press ENT key, the following screen appears:
Press numeric keys to input the desired value, and press “ ENTR ” soft key to confirm. Then the screen
return to the first page of Simulated Output #1 menu.
Use the same method to set the Output Filter.
2006-3-21 12:00:00 Scale#1
SIMULATED OUTPUT #1
Type: [RATE ]
Range: [ 4-20 mA ]
Delay: [ 0 sec ]
Filter: [ 0 ]
Press
↑
or
↓
key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
2006-3-21 12:00:00 Scale #1
SIMULATED OUTPUT #1
Type: [ RATE ]
Range: [ 4-20 mA ]
Delay : 0
Filter: [ 0 ]
Press
↑
or
↓
key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
