P ress the U p/ D own scroll keys to move the cursor to the item that to be set, followed by [ENT] key.
Press ENTR soft key to view the optional settings and press SURE soft key until the desired value is
displayed.
Function: NO DEFINE, MODBUS , PRINT
Baud Rate: 4800 , 9600 , 19200 , 38400 , 115200
Word Length: 8 BIT, 7 BIT
Stop Bit: 1 BIT, 2 BIT
Pressing “ PAGE DOWN ” soft key enters the second page of the Communication Menu.
Parity: NONE, EVEN, ODD
Address: 1-255
Pressing “ PAGE DOWN ” soft key enters the third page of the Communication Menu.
2006-3-21 12:00:00 Scale#1
COMMPORT 1 SETUP
Parity: [ NONE ]
Address: [ 1 ]
Press ↑ or ↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
2006-3-21 12:00:00 Scale#1
COMMPORT 2 SETUP
Function: [ MODBUS ]
Baud Rate: [ 115200 ]
Word Length: [ 8 BIT ]
Stop Bit: [ 1 BIT ]
Press
↑
or
↓
key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
