SainSmart Genmitsu - Wire Sorting & Commissioning Prep

34
Part 2: Mechanical installation
NAME QTY.NO.
Operation
Steps
Prepare
materials
VIEW 1
VIEW 2
CODE
Tools
Check
Cable tie (Black) 1
1
MX3-45
MX3-49
Use cable tie to fix all the wires which across the wire
holder.
Use the Nylon braided tube to bundle the multi-wires.
1
2
1
2
Nylon braided tube
MX3-49
use here
MX3-45
use here
Step 25: Sorting wires & Prepare Commissioning
Caution
Before you want to power on the CNC machine and
commissioning, plase add the Lubricating oil to the lead
screw(X/Y Axis).
Lubricating oil ( provide by yourself )
1
