SainSmart Genmitsu - Spindle Motor Wiring

33
Part 2: Mechanical installation
NAME QTY.
Step 24: Wiring Spindle motor wires
NO.
Operation
Steps
Prepare
materials
VIEW 1
VIEW 2
CODE
Tools
Check
Remind
Spindle motor wires 35cm
Use the spindle motor wire insert the Control board,
NOTE: Red wire to M +, Black wire to M -
1 1
1
1
MX3-38
Pay attention the mark on the Control board, make sure
the correct sequence and direction of the connectors.
MX3-38
