SainSmart Genmitsu - Stepper Motor Wiring

32
Part 2: Mechanical installation
NAME QTY.
Step 23: Wiring Connecting wires (Stepper motors)
NO.
Operation
Steps
Prepare
materials
VIEW 1
VIEW 2
CODE
Tools
Check
Remind
(X Axis) Stepper motor connecting
wire 17cm
(Y Axis) Stepper motor connecting
wire 52cm
(Z Axis) Stepper motor connecting
wire 28cm
Use the Stepper motor connecting wire connect the
control board and motors.
Pay attention the mark on the Control board, make sure
the correct sequence and direction of the connectors.
1
2
3
1
1
1
1
1
MX3-35
MX3-36
MX3-37
MX3-35
MX3-37
MX3-36
