SainSmart Genmitsu - Z-Axis Limit Switch Wiring

31
Part 2: Mechanical installation
NAME QTY.
Step 22: Wiring Connecting wires (Z Axis Limit Switch)
NO.
Operation
Steps
Prepare
materials
VIEW 1
VIEW 2
CODE
Tools
Check
Remind
Limit Switch Connecting wire
Z LIM + 34cm
1
1
MX3-33
MX3-34
Put Limit switch connecting wire insert the Control board
and Limit switch, the switch near by the motor is the LIM+.
Pay attention the mark on the Control board, make sure
the correct sequence and direction of the connectors.
1
2
1
1
Limit Switch Connecting wire
Z LIM - 40cm
MX3-33
MX3-34
