SAJ B1 Series User Manual

B1 Series
- 9 -
2.3 Datasheet
B1-5.1-48
Type
B1-5.1-48
Electrical Parameters
Total Energy Capacity[Wh]
5120
Usable Capacity [Wh]
4600
Rated Voltage [V]
51.2
Voltage range [V]
42~58.4
Depth Of Discharge[DOD]
≤90%
Cycle Life
≥6000
Max.Charge Current [A]
60
Max.Discharge Current [A]
60
Physical Parameters
Battery Type
Lithium-ion phosphate (LiFePO4)
Communication
CAN
Operating Temperature Range
0°C~50°C
Cooling Method
Natural Convection
Ambient Humidity
0-95% Non-condensing
Ingress Protection
IP65
Dimensions[H*W*D][mm]
410*650*186
Weight [kg]
48
Standard Warranty [Year]
5(Standard)/10(Optional)
Applicable Standard
UN38.3、IEC62619
