B1 Series

- 12 -

3.2.3 Mounting Method

A vertical mounting is recommended and the battery accepts backwards tilt

by max.15°. Never mount the battery horizontally or upside down.

√ √

× × ×

Figure 3.3 Mounting method

Please ensure a good air circulation at the installation area. Because poor

air ventilation will affect the working performance of internal electronic

components and shorten the service life of the system.

50CM

Figure 3.4 Installation position
