PRODUCT
INFORMATION
3.1 Application Scope of Products
R6 series product is grid-tied single phase inverter without transformer. The product converts the DC
generated by solar panels into AC which is in accordance with the requirements of public grid and send the
AC into the grid, Figure 3.1 shows the structural diagram of the typical application system of R6 inverter.
Figure 3.1
R6 series application
3.2 Specification for Product Model
R6 – XK – S3 -X/A
① ② ③ ④
① R6 represents for product name.
② XK represents rated power XkW of inverter, for example, 10K means 10kW.
③ S means single phase; 3 represents the inverter has the function of three MPPT.
④ X is used to distinguish S2 from S3; A indicates this model is ONLY applicable to Australia
