INTRODUCTION
1.8 Revised 08/08/2013
Specifications
Models
Model
Name/Description
4740
Tissue-Tek
®
Film
®
Coverslipper (115 VAC) (USA)
4741
Tissue-Tek
®
Film
®
Coverslipper (100 VAC) (Asia)
4742
Tissue-Tek
®
Film
®
Coverslipper (230 VAC) (Europe)
4743
Tissue-Tek
®
Film
®
Coverslipper BCR (115 VAC) (USA)
Power Ratings and Requirements
Model
Voltage
Frequency
Amps
4740/4743
115 VAC ± 10% @ <15A
60 Hz
1.3A
4742
230 VAC ± 10% @ < 7A
50/60 Hz
0.8A
4741
100 VAC ±10% @ <15A
50/60 Hz
1.5A
Safety Standards
Tested and listed by Intertek Testing Services (ITS).
Complies with IEC 61010-1 2
nd
Ed., CAN/CSA C22.2 No.
61010-1 2
nd
Ed., UL 61010-1 2
nd
Ed.
CE registered in compliance with the requirements of
EMC Directive, LV Directive in Europe, In Vitro Diagnostic
Device Directive.
Dimensions
Centimeters: 72(W) x 58(D) x 69(H)
Inches: 28(W) x 23(D) x 27(H)
Instrument Weight
75 kg (165 lbs.)
Operating Conditions
Operating temperature: 10º C to 40º C (50º F to 104º F)
Relative humidity: 30-85% (non-condensing)
Atmospheric pressure: 70kPa to 106kPa
Protect from direct sunlight.
Storage Conditions
Storage temperature: -10º C to 60º C (º F to º F
Relative humidity: 30-95% (non-condensing)
Atmospheric pressure: 70kPa to 106kPa
Processing Speed
Maximum throughput: 1,080 slides per hour
60 slides/batch
Acceptable Slide Dimensions
Dimensions: 24.7 to 26.5 mm (W) x 74.7 to 76.5 mm (L)
Thickness: 0.9 to 1.2 mm thickness
Compatible Solvent
Reagent grade or analytical grade xylene only
Coverslipping Film
Width: 24 mm
Length: 45, 50, 55, and 60 mm
Material-Cellulose Triacetate with Resin and Back
Coatings
CAUTION: Xylene substitutes are not compatible for
use on the Tissue-Tek
®
Film
®
Coverslipper.
