BAR CODE READER
A.2 Revised 08/08/2013
Weight: 2 oz. (57 g)
Types of Barcode Symbologies that can be read:
A. Linear (1D) barcodes
Code 39, Code128/EAN128, BC412, Interleaved 2 of
5, Code93, Codabar, UPC/EAN, Postal Symbologies,
GS1 DataBar (RSS)
B. 2D barcodes
Data Matrix (ECCO-200), Aztec Code, QR Code,
Micro QR Code, PDF417, Micro PDF417 Stacked
Symbologies PDF417, MicroPDF417, GS1 DataBar
(RSS) (Composite and Stacked)
C. Composite symbols
Combinations of 1D barcodes (EAN-128, UPC-A,
EAN-13, EAN-8, UPC-E, GS1 DataBar (RSS)) and
2D barcodes (PDF417, Micro PDF417)
Connector:
USB type A connector - included. High Density 15-pin D-
Sub socket connector supported. 0006958-01 Rev.A
Communications Protocols:
Standard Interfaces:
USB (installed), RS-232, RS-422 Data Output: ASCII
Indicators
LEDS: Read Performance, Power,
Read Status
Green Flash: Good Read
Blue Target Pattern: Symbol locator
Beeper: Good Read, match/mismatch,
No Read, serial command
confirmation, on/off
Read Parameters
Pitch: ±30° Skew: ±30° Tilt: 360°
Decode Rate: Up to 4 decodes per second
Focal Range: 2 to 6” (50.8 to 152.4 mm)
(autofocus)
Other Specs
Light Source:
Type:
High-output LEDs. Light Collection Options Progressive
scan, square pixel; Software adjustable
shutter speed, electronic shutter.
General Immunity for Light Industry:
EN 55024:1998+A1:2001+A2:2003
Radiated and Conducted Emissions of ITE Equipment:
EN 55022:1998+A1:2000+A2:2003
for Class A products
Maximum LED output:
.564 mW.
Wavelength:
470 nm; 525 nm; 617 nm
WVGA:
752 x 480 pixels
Statement of Agency Compliance
The Quadrus MINI Velocity has been tested for
compliance with FCC (Federal Communications
Commission) regulations and has been found to conform
to all applicable FCC rules and regulations.
To comply with FCC RF exposure compliance
requirements, this device must not be co-located or
operate in conjunction with any other antenna or transmitter.
Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s
authority to operate the equipment.
The Quadrus MINI Velocity has been tested for
compliance with CE (Conformité Européenne) standards
and guidelines, and has been found to conform to
applicable CE standards, specifically the EMC
requirements EN 55024:1998+A1:2001+A2:2003, ESD
EN 61000-4-2, Radiated RF Immunity EN 61000-4-3, ENV
50204, EFT EN 61000-4-4, Conducted RF Immunity EN
61000-4-6, EN 55022:1998+A1:2000+A2:2003 for Class A
products, Class B Radiated Emissions, and Class B
Conducted Emissions.
The Quadrus MINI Velocity has been tested by an
independent electromagnetic compatibility laboratory in
accordance with the applicable specifications and
instructions..
