33
Smarty 2X/3X V
www.salda.lt
DRAWN BY
CHECKED BY
SIGNATUREDUTIES / NAME DATE
UAB"SALDA"
Drawing #
Book #
CHECKED BY
1 1 2 3 4 4 5 6 7 7
EI D. Aleksandravičius
EI A. Šklenikas
Aut. 219.1017E
219.1017.0.1.3-PS
Principle connection scheme
1
03
2016-03-22
2016-03-22
2016-03-22
Punktyrine linija pažymėtus komponentus ir kabelius pajungia SALDA arba vartotojas.
Components and cables marked with the dash line connected by SALDA or customer.
230VAC
ON/OFF
N
L1
L1
M2
230VAC
ON/OFF
N
L1
L1
M3
Vin
GND
AO1
Transmitter 1
-System mode switch
-Fan speed switch
32
3031
J3 J4
33
Extract air CO2 or
RH (input 0-10VDC)
TE
Optional.
Extract air
temperature sensor
X7:5 - AI4(0-10V)
X7:6 - GND
X7:7 - +24VDC
-N1
miniMCB V0.3
X7:1 - DI9
X7:2 - 3.3V_1W
X7:3 - DI10
X7:4 - 3.3V_1W
-N1
miniMCB V0.3
X6:7 - AI4(NTC)
X6:8 - GND
-N1
miniMCB V0.3
X13:1 - PE
X13:2 - N(L1)
X13:3 - DO3(L(L2))
X13:4 - DO4(L(L2))
X14:3 - PE
-N1
miniMCB V0.3
Alarm
indication
output
(STOP)
Working
indication
output
(START)
(for versions 1.1)
=MCB1-H1 =MCB1-H2
29 28
27 26
Supply air CO2 or
RH (input 0-10VDC)
Vin
GND
AO1
Transmitter 2
X21:1 - DO1
X21:2 - 24VDC
X21:3 - DO2
X21:4 - 24VDC
-N2
miniEX1 V0.3
X19:1 - AI(0-10V)
X19:2 - GND
X19:3 - 24VDC
-N2
miniEX1 V0.3
