Salda SMARTY XV Series User Manual

54
Smarty 2X/3X V
www.salda.lt
Bypass damper
Damper***
GPUSK227_1016_1016
Electrical heater
Heater
ZSIS220_1017_1017
Control board without
presure sensores
Mini MCB*
GAUSM219_1017_1045
Control board
Mini MCB Basic**
GAUSM219_1017_1020
Smarty 2X V door
Door
GPUD232_1027_0
Heat exchanger
Heat exchanger
ZSLPLGS0024
Temperature sensor 3 m
TJ
PJUT0063
Temperature sensor 1,5 m
TL/TA
PJUT0062
Supply/extract air fan
Fan
GPUVM224_1026_1026
* Smarty 2X V 1.1 version only
** Smarty 2X V 1.2 and V 1.3 versions only.
*** Smarty 2X V 1.1 and V 1.2 versions only.
