Smarty 2X/3X V
www.salda.lt
Product Smarty 2X/3X V 1.1 version can be equipped with either electric or water heater.
The electric heater can be controlled by:
- On/O󰀨 – control of electric heater up to 0.6kW/230V or the circulation pump.
- 0-10V – control of electric or water heater.
- Electric heater control by On/O󰀨.
Installation diagram.
Electric heater shall be installed inside air duct. Arrangement based on air direction Electric Heater -> Supply Air Sensor (TJ).
KE
Mini MCB
TJ
Wiring diagram.
On/O󰀨 heater connection. Automation controller D zone X10
and C zone X23. This control method is suitable only to electric
heaters up to 0.6 kW/230 V. In order to control more powerful
heater above 0.6 kW by On/O󰀨 method, intermediate relay shall
be used where power circuit shall be connected to a separate
power supply.
DI1
+12VDC
DI2
DI3
+12VDC
DI4
+12VDC
1 2 3 4 5 6 7 8
+12VDC
AT1
AT1
RT1
RT1
EKA ... -1F
PE
3 2 1
DO1 (L(L2)_2)
N(L1)_2
PE
N
L
EKA ... -1F
max. 0,6kW;
2,6A; 230V
CO
2
concentration [ppm]
3000 E󰀨ect on an individual
2500
2000
Reduced concentration, drowsi-
ness, headache, etc.
1500
1000 Pettenkofer limit
Pettenkofer limit Disturbs
500 Pleasant
0
0 1 2 3 4
Duration of the presence in the room in hours
C
l
o
s
e
d
w
i
n
d
o
w
s
C
o
n
t
r
o
l
l
e
d
v
e
n
ti
l
a
t
io
n
Outdoor air
