70
Nominal power (kVA) 7,5 10 15 20 30 40 50 60 80 100 120 160 200
Nominal power (kW) Depending on the input/output setting and power supply voltage (See chart 9)
Permissible overload 400 % for 10 s
Transference to bypass Immediate, for overloads higher than 150 %
Re-transference Automatic after alarm cancelling
Efficiency on Smart Eco-mode 95 95.5 96 97.4 97.8 98 98.4 98
MANUAL BYPASS (MAINTENANCE)
Type Make before break
Nominal voltage
Single phase 220V, 230V or 240V -
Three phase 3x380V, 3x400V or 3x415V (4 wires: 3 phases + N)
Frequency 50 or 60 Hz
GENERAL
Total efficiency (100% linear load) (%) 91.0 91.5 92.0 93.0 93.5 94.0 95.0 94.5 94.0 95.0
BATTERIES
Quantity 31 + 31
(***) Type Pb Ca
Floating voltage per battery 13.65 V at 20ºC
Compensation of the battery floating voltage Adjustable (Preset to –18 mV/ºC)
Capacity (Ah) 4.5 9 12 2x12= 24 40 65 80
Standard charging current (Cx0,2) (A) 0.9 1.8 2.4 4.8 8.0 13 16
Battery terminal torque According to battery manufacturer
Fitted in the same UPS cabinet YES NO
DIMENSIONS AND WEIGHTS FOR UPS CONFIGURATIONS WITH STANDARD BACK UP TIME
Quantity of cabinets 1 (UPS + batteries) 1 (UPS) / 1 (batteries)
Maximum
dimensions(mm)
(Depth x Width x
Height)
CUBE3+ / CUBE3+ B1
770x450x1100
875x590x1320 850x900x1900
CUBE3+ B / CUBE3+ B B1
875x590x1320
875x870x1320 850x1225x1900
Batteries - 770x450x1100 1050x650x1320 850x1300x1900
Casters without brake. Equipment / batteries YES / - YES / YES YES / NO NO / NO
Cabinet weight (kg)
CUBE3+ B1 100 100 102 105 150 175 - - - - - - -
CUBE3+ B B1 102 102 104 107 153 178 - - - - - - -
CUBE3+ 210 210 212 215 310 400 185 185 265 290 290 540 550
CUBE3+ B 212 212 214 217 313 403 190 190 275 310 310 570 580
External batteries - - - - - - 510 510 1020 1020 1020 1655 1690
Tabla 8. Technical specifications of equipments with (HV) voltage.
Additional informations referred to charts 7 and 8:
• UPSs up to 20 kVA (LV) / 40 kVA (HV) with standard
back up time are supplied in only one cabinet, bat-
teries included. For extended back up times and/or
higher power rates, the UPS and batteries are sup-
plied in separate cabinets.
(*) P.F. 0.9 is only available in III / III configurations up to
60 kVA (LV) / 120 kVA (HV). Rest of configurations (L,
M or N) and power range rate, P.F. 0.8.
(**) Permissible overload per phase or total overload at
P.F. 0.8.
(***) Batteries fitted in as standard are Pb-Ca type.
As an option Ni-Cd batteries can be supplied, fitted in
a separate cabinet or rack.
It is also possible to have a common battery set of
Pb-Ca or Ni-Cd type fitted in a cabinet or rack, for two
equipments in parallel.
CUBE3+ B Equipment with separate bypass line.
CUBE3+ B B1 Equipment with separate bypass line, nei-
ther batteries nor accessories (bolts, ca-
bles,... ).
Model
Input-output
configuration
Votage
(V)
Power (kVA / kW)
Config.
III/III
Config.
L / M / N
SLC-5-CUBE3+
No ref. : III / III
L : I / I
M : I / III
N : III / I
«LV»
3x200.. 3x230 V
(115.. 133 V in single phase)
5 / 4,5 5 / 4
SLC-7,5-CUBE3+ 7,5 / 6,75 7,5 / 6
SLC-10-CUBE3+ 10 / 9 10 / 8
SLC-15-CUBE3+ 15 / 13,5 15 / 12
SLC-20-CUBE3+ 20 / 18 20 / 16
SLC-30-CUBE3+ 30 / 27 30 / 24
SLC-40-CUBE3+
Available
in III / III
configuration
only
40 / 36 40 / 32
SLC-50-CUBE3+ 50 / 45 50 / 40
SLC-60-CUBE3+ 60 / 54 60 / 48
SLC-80-CUBE3+ 80 / 64 80 / 64
SLC-100-CUBE3+ 100 / 80 100 / 80
SLC-7,5-CUBE3+
No ref. : III / III
L : I / I
M : I / III
N : III / I
«HV»
3x380.. 3x415 V
(220.. 240 V in single phase)
7,5 / 6,75 7,5 / 6
SLC-10-CUBE3+ 10 / 9 10 / 8
SLC-15-CUBE3+ 15 / 13,5 15 / 12
SLC-20-CUBE3+ 20 / 18 20 / 16
SLC-30-CUBE3+ 30 / 27 30 / 24
SLC-40-CUBE3+ 40 / 36 40 / 32
SLC-50-CUBE3+ 50 / 45 50 / 40
SLC-60-CUBE3+ 60 / 54 60 / 48
SLC-80-CUBE3+
Available
in III / III
configuration
only
80 / 72 80 / 64
SLC-100-CUBE3+ 100 / 90 100 / 80
SLC-120-CUBE3+ 120 / 108 120 / 96
SLC-160-CUBE3+ 160 / 128 160 / 128
SLC-200-CUBE3+ 200 / 160 200 / 160
Tabla 9. Powers according to model, configuration and operating voltage.
