12 Product Support 1-888-202-9831
8.2. CONTROL PANEL
The front face of the sam Power Controller contains a control panel. The LEDs on the
control panel are divided into a field for Battery Indicator and a field for Treatment Timer.
The operator is able to make selections by pressing the Power Button and the Toggle
Button.
Color of Battery Indicator LED* Meaning
Red Only Low Battery, Re-Charge required
Blinking Red Re-Charge required
Amber Power Controller is partially charged
Green Power Controller fully charged
*These lights remain on for 4 seconds and subsequently turn off
Table 2. Battery Indicator LED Color Definitions
Treatment Time Indicator LED Meaning
Blue Treatment time remaining. Treatment
timer is set in one hour increments.
Amber Treatment complete. This single “done”
light will activate only when a treatment
cycle has completed and will remain
illuminated for 8 hours, then turn off
Table 3. Treatment Time Indicator LED Color Definitions
8.3. APPLICATOR INDICATOR LED
LED Color Meaning
Opaque (absence of light) Applicator is not receiving power
Blue Applicator is receiving power from the
Power Controller. Ultrasonic energy is
being generated at all times this light
is illuminated
Red (accompanied by vibration) sam Sensing Mode. No Ultrasonic energy
is being generated from this applicator
while this light is illuminated
Table 4. Applicator LED Color Definitions
