B. SPECIFICATIONS
The sam Device does not contain microprocessor or software to control function
Maximum Acoustic 0.65 W
+
20% per transducer
Power Output 1.3 W
+
20% for 2 transducers
Maximum Intensity 0.132 W/cm
2
+
20%
Frequency 3 MHz
+
20%
Duty Cycle 100% - continuous wave
Beam Form Wide Beam – 5 degree diverging lens
Individual Transducer Dimension 5 cm
2
emitting surface area (circular)
BNR <5:1
ERA 6 cm
2
+
20 %
Maximum Treatment Duration 4 hours
Other Electrical Ratings for the sam Device Components
Electrical Charger (Model SINGOF10U050200)
Input Voltage 100240 V, 5060 Hz
Input Current 0.120.3 A
Output Voltage 4.755.25 V DC
Output Current 2.0 A
Max Output Power 10.5 W
Power Controller
Output Voltage 3.7 V DC
+
10%
Max Output Amperes 700 mA
Battery Protection Max Current: 2 Amps
Max Voltage: 4.2 V
Min Voltage: 3.1 V
Cable Voltage Rating 300 V
Cable 20°C Resistance: 94/km
