11.2. CONNECT APPLICATOR TO POWER CONTROLLER
* If using 2 applicators: first connect the Y-adapter directly to the power controller
wire jack and then connect each applicator to a wire jack at the other end of the
Y-adapter (Figure 8*).
A. Insert the power controller wire into the matching cavity at the base of the
applicator at a 45 degree angle (Figure 8A).
B. Gently twist the wire jack clockwise until the applicator edge is flush with the
wire jack (Figure 8B).
4
HRS
3
2
1
DONE
B
A
T
T
E
R
Y
C
H
E
C
K
figure 8*: Connecting Y-Adapter
45
Rotate Clockwise
figure 8B: Gently twist to Lock
45
Rotate Clockwise
figure 8A: Insert power controller wire at 45
0
angle
