Recommended length of safety device spring R (Fig. 17) should be 143 mm. If the safety device
breaks away too easily, tighten up the spring approximately 1-2 mm. DO NOT tighten up too much,
because you may prevent the safety device from working and damage the mower.
5.7.3. Removing clogging and jams
When operating the mower pay attention to variable conditions on field, which may influence the
mower clogging and jams, such as: terrain unevenness, height and density of grass as well as other
objects in the grass (stones, branches, piles of soil). In order to avoid clogging and jams, operating
speed should be adjusted to the mentioned conditions.
WARNING!
Removing clogs and jams while the machine is in operation can lead to the
accident!
In case of machine blockage caused by wrapped material, set the machine on a flat surface, remove
excess material using sharp tool. After clearing the machine check if nothing has been damaged.
To remove any clogging it is obligatory to disconnect the drive and the motor, take out the ignition
key. When eliminating any clogging on the machine, use also safety means for operator, so protective
gloves and tight wear.
5.7.4. Taking turns over swaths
Lift the mower with hydraulic cylinder and take the turn. The mower does not need to be
additionaly lifted by tractor’s 3-point linkage.
5.8. Dismounting mower from tractor
WARNING!
When dismounting, make sure there is no person in between the mower and the
tractor.
To dismount the mower from the tractor:
❑ left the swath,
❑ turn cutterbar's drive off,
❑ place the mower on even, paved ground, lower and protect support legs, check, if the mower is
properly protected against falling,
❑ turn the tractor's engine off and take ignition key off,
❑ dismount tractor's rpm and place it on a PTO shaft holder, that is standard-delivered with the
mower,
