SAMCHULLY HCH - Page 39

C
A
W
J
G
H
F
D
Q
R P
N
M
V
B
L
K
SERRATION PITCH 1.5
(HCH 21-32 SERRATION PITCH 3.0)
E
Grease
C
A
W
J
G
H
F
D
Q
R P
N
M
V
B
L
K
SERRATION PITCH 1.5
(HCH 21-32 SERRATION PITCH 3.0)
E
HCHF-32(4-Jaw)
HCHF-21, 24(4-Jaw)
30°
15°
15°
30°
30°
30°
15°
15°
6
65 25
H8/h8
10
3.5
25.5
22
22
16
37
T
U
HCHT-15(2-Jaw) HCHF-15, 18(4-Jaw)
T
U
30°
15°
15°
30°
30°
15°
15°
30°
T
U
U
T
30°
15°
45°
15°
45°
T
U
5
M/JAW 첫산위치
39
Instruction Manual
Instruction Manual
형식
Type
型式
허용최고
회전속도
Max. R.P.M.
最大转速
[min
-1
(r.p.m.)]
중량
Weight
重量
[kgf]
관성모멘트
GD²
转动惯量
[N·m²(kgf·m²)]
적용실린더
Operating Cylinder
工作缸
최대설정 유압력
Max. Hydraulic
Pressure
最大液压压力
[Mpa(kgf/cm²)]
적용죠
Operating
Hard Jaw
工作硬爪
호환모델
KITAGAWA®
Model
北川型号
HCHT-15 2500 115 87.28(8.90) SH-25011 1.50(15.3) HB15A1 BT-15
HCHF-15 2500 115 87.30(8.90) SH-25011 1.50(15.3) HB15A1 -
HCHF-18 2000 159 165.80(16.90) SH-25011 1.50(15.3) HB15A1 -
HCHF-21 1700 235 351.20(35.80) SH-25011 1.97(20.1) HB18B2 -
HCHF-24 1400 293 651.40(66.40) SH-25011 1.97(20.1) HB18B2 -
HCHF-32 1200 530 601.00(61.00) SYHL-2816 2.20(22.4) HB32B2 -
형식
Type
型式
관통경
Thru Hole Dia.
通孔直径
[mm]
파악경
Grip Dia.
软爪的夹范围
[mm]
죠 스트로크 직경
Jaw-Stroke Dia.
爪行程(直径)
[mm]
플런져 스트로크
Plunger Stroke
柱塞行程
[mm]
허용최대입력
Max. Permissible
Input Force
允许输入力
[kN(kgf)]
최대정적 파악력
Max. Static
Grip Force
最大静态夹持力
[kN(kgf)]
Max. Min.
HCHT-15 117.5 381 30 10.6 23 47(4793) 120(12236)
HCHF-15 117.5 381 30 10.6 23 47(4793) 120(12236)
HCHF-18 117.5 450 30 10.6 23 47(4793) 120(12236)
HCHF-21 140.0 530 87 10.6 23 60(6117) 156(15907)
HCHF-24 166.5 610 110 10.6 23 60(6117) 156(15907)
HCHF-32 240.0 800 160 18.0 34 67(6795) 156(15821)
HCHT / HCHF
사양 / Specification / 技术参数
