SAMES KREMLIN Inogun M - Page 41

Index revision : C - July 2021 41 7132
(*)
Level 1: Standard preventive maintenance or breakable part possible during an intervention
Level 2: Corrective maintenance
Level 3: Exceptional maintenance
Item Part Number Description Qty
Unit
of
sale
Maintenance
level for
spare parts (*)
910031951
Equipped Inogun M + gun
(with cable length: 6 m)
11 3
910031951-12
Equipped Inogun M + gun
(with cable length: 12 m)
1 1 3
1
X3GJBP484 Zinc plated screw PT KA30x20 WN1411 5 1 3
X3BDZU003 Washer Z 3 U zinc-plated steel 5 1 3
2 X2BDVX003 Fan washer AZ3 1 1 3
3 910030494 Inogun M control box 1 1 3
4 J2FTCF051 O-ring (included in item 5) 1 1 1
5 910031489 High voltage unit 100kV 1 1 3
6
910029997 Inogun M equipped fixing hook 1 1 3
X3GJBP484 Screw PT KA 30 X 20 WN 1411 2 1 3
7 910033168 Barrel assembly (see § 9.2 page 42) 11 3
8 910028157 HV contact with o-ring 1 1 2
9 J2FTDF027 O-ring (included in item 8) 1 1 1
10 910027640
Electrode support
(see § 9.4.1 page 44
)
11 1
11 900016321
Medium flat spray deflector
(see § 9.4.1 page 44
)
11 1
12 900018342 Nozzle nut 1 1 3
13 910029995 Powder duct 11 3
14 J2FTDF177 O-ring (included in item13) 1 1 1
15
910029134 Equipped low voltage cable (lg: 6m) 1 1 3
910029182 Equipped low voltage cable (lg: 12m) 1 1 3
16
130001649-6 Powder hose POE 11mm green (lg: 6m) 1 1 1
130001649-12 Powder hose POE 11mm green (lg: 12m) 1 1 1
130001649-18 Powder hose POE 11mm green (lg: 18m) 1 1 1
17 910029994 Powder connector assembly 1 1
1
18 J2CTCN022 O-ring (included in item17) 1 1 1
19 910029996
Handle assembly
(see § 9.3 page 43
)
11 3
20 250000313 Zinc plated screw PT KA30x10 WN1411 6 1 3
Option
910027641
Round spray electrode support
(see § 9.4.3 page 47
)
11 3
1409259
Round spray deflector, Dia.: 16 mm
(white)(see § 9.4.3 page 47
)
11 1
