FPro G
II2G Ex h IIB T6 Gb X
User manual 582166110
2021-03-11
Index A
Original manual
SAMES KREMLIN SAS
13 Ch emin de Malacher
38240 Meylan
www.sames-kremlin.com
33 (0)4 76 41 60 60

Table of Contents

Other manuals for SAMES KREMLIN FPro G

Questions and Answers

  • K
    Kara RomanAug 19, 2025
    What to do if SAMES KREMLIN FPro G leaks product at the front when the trigger is released?
    • K
      Katie RitterAug 19, 2025
      If paint is leaking from the front of your SAMES KREMLIN Paint Sprayer when the trigger is released, it could be due to impurities in the product. Try pulling the trigger 3 or 4 times and letting it return on its own. Alternatively, the needle or nozzle might be worn out, requiring replacement.
  • J
    Jon HamptonAug 21, 2025
    Why is the SAMES KREMLIN FPro G spraying product jerkily?
    • C
      cbrownAug 21, 2025
      If your SAMES KREMLIN Paint Sprayer is experiencing jerky product spray, it's likely due to air entering the paint circuit. Here's what to check: * Ensure the paint container isn't empty and refill if needed. * Tighten the nozzle properly; if the issue continues, disassemble and clean it. * Inspect the nozzle seat and cone for damage, then reassemble securely. * Confirm the paint is fluid and homogeneous enough for vacuuming.
  • S
    Sarah GarciaAug 23, 2025
    How to fix SAMES KREMLIN FPro G when paint no longer comes out?
    • J
      John ReynoldsAug 23, 2025
      If your SAMES KREMLIN Paint Sprayer isn't dispensing paint, the nozzle is likely clogged. To resolve this, disassemble the nozzle and clean it thoroughly with solvent and a smooth brush. Also, inspect the condition of the seal.
  • C
    carlymendezAug 26, 2025
    Why does the head of my SAMES KREMLIN Paint Sprayer get dirty so often?
    • M
      michealbennettAug 27, 2025
      If the head of your SAMES KREMLIN Paint Sprayer frequently gets dirty, it's likely due to excessive air pressure. Reduce the air pressure to resolve this issue.
  • J
    johnaguilarAug 28, 2025
    Why is paint coming out of the air holes in my SAMES KREMLIN Paint Sprayer head?
    • J
      Jillian EdwardsAug 28, 2025
      If the paint is coming out through the air holes in the head of your SAMES KREMLIN Paint Sprayer, it's either due to a defective nozzle seal (which needs replacement) or an insufficiently tight nozzle (which needs tightening).
  • C
    Colton WilkinsAug 30, 2025
    Why is the spray from my SAMES KREMLIN Paint Sprayer loaded in the center?
    • K
      Kristen LeonardAug 30, 2025
      If your SAMES KREMLIN Paint Sprayer has a spray that is loaded in the center, it could be due to a couple of reasons. Either the paint flow rate is too high for the spraying air pressure (increase the spraying air pressure and reduce the paint flow rate), or the paint is too thick (dilute it).
  • W
    wjohnsonSep 1, 2025
    Why is my SAMES KREMLIN FPro G leaking air at the valve?
    • S
      Stephen DeanSep 1, 2025
      If you're experiencing air leakage at the valve of your SAMES KREMLIN Paint Sprayer, it indicates a worn valve that needs replacement.
  • M
    Monica UnderwoodSep 4, 2025
    How to stop permanent air leakage at the gun head of SAMES KREMLIN Paint Sprayer?
    • S
      Samuel HartSep 4, 2025
      If you notice a permanent air leakage at the gun head of your SAMES KREMLIN Paint Sprayer when the trigger is released, it could be due to rubbing on the needle or a worn valve. Remove the trigger and check that the needle slides freely. If the issue persists, consider replacing the valve.
  • Z
    zrodgersSep 6, 2025
    What to do if SAMES KREMLIN FPro G has a cutted spray?
    • C
      cbarnesSep 7, 2025
      If your SAMES KREMLIN Paint Sprayer has a cutted spray, it means that the air pressure at the vents is too high for the paint flow. You can fix this by reducing the air at the vents by closing the adjustment needle to narrow the spray, or by increasing the paint flow.
  • P
    Paul BenitezSep 8, 2025
    Why is my SAMES KREMLIN FPro G Paint Sprayer leaking product at the trim level?
    • B
      Brittany SmithSep 8, 2025
      If you're experiencing product leakage at the trim level of your SAMES KREMLIN Paint Sprayer, it's likely due to a worn seal. Try tightening the liner press without blocking the needle. If the leak persists, replace the seal and needle.

Summary

Warranty

Meanings of Pictograms

Qualification of Personnel

Safety Instructions

Life Safety

General safety advice for product usage and handling.

Personal Protective Equipment and Workstation

Guidance on required PPE and workstation setup for safe operation.

Grounding

Integrity of the Material

Equipment Modification

Rules and consequences regarding equipment modification and part usage.

Environment

EU Declaration of Conformity

Presentation of FPro G

Usage

Recommended applications and product feeding method for the gun.

FPro G Gun Components

Dimensions FPROG - FPRO GSP

Gun Structure FPROG and FPRO GSP

Equipment Identification

Material Plan

Explains the designation structure for identifying equipment models.

Options

Disposable Cup - Smart Cup

Information on disposable cups as an optional accessory.

Versions FPro G

Standards Applied

Description of the ATEX Marking

Visuals of the Marking Elements

Technical Specifications and Performance

Technical Specifications

Detailed technical data for different FPro G models.

Materials FPro G

Air and Fluid Connections

Nozzle Characterization Principle

Performances

Principle of Operation

Explains how the pneumatic spray gun operates and its adjustments.

Installation

General Installation Diagram

Illustrates the typical installation setup and safety zones.

Installation Diagram - Air Pressure Adjustment

Transport

Storage

Commissioning

Apply a Product on a Surface

Step-by-step guide for applying product using the spray gun.

Short Stop of the Gun

Procedure for temporary pausing operations of the spray gun.

Prolonged Shutdown of the Gun

Steps for safely shutting down the gun for an extended period.

User Settings

Ergonomic GSP Position Adjustment

Initialization of Follow-up in Production

Safety in Production

Use of the FPro G

First Commissioning

Reference to the initial setup and commissioning procedure.

Diagnostic Help; Troubleshooting Guide

Possible Symptoms, Causes, and Remedies

Table detailing common faults, their causes, and recommended solutions.

Maintenance

Preventive Maintenance Plan

Schedule and details for planned preventative maintenance tasks.

Location of Lubrication Points

Cleaning

Corrective Maintenance

Disassembly;Re-assembly Operation

Dismantle the FPro G

Steps for disassembling the FPro G spray gun for maintenance.

Replace Needle Packing

Replace Air Valve

Replace Air Valve Seal

Replace Air Needle

Replace the GSP Kit

Replace the Air Connection

Replace the Gravity Cup

Replace of Defective Parts

Disposable Cups: Smart Cups

Assembly Instructions

Step-by-step guide for assembling disposable smart cups.

Storage Instructions

Disposal Instructions

Spare Parts

Commercial References

Lists part numbers and designations for various FPro G models.

Exploded View of the FPro G Gun

Exploded View of the FPro GSP Gun

Consumable References

Wear Part References

References for Spare Parts or Repair Kits

Kit References - Specific Tools

Lists references for specialized tool kits and connectors.

Lubricants

Lists recommended lubricants for maintenance.
