CONSTRUCTION, LAYOUT & CONTROLS
• Display of BULK and FLOAT voltage setting value
• Display of Equalization Voltage, Equalization Time and Equalization Interval
• Display of heat sink (the front panel metal plate acts as the heat sink) temperature
and battery temperature through the optional Battery Temperature Sensor (BTS).
* NOTE: As the display is not capable of showing negative values, battery temperature below 0 ºC will not
be displayed. Voltage compensation will, however, be carried out even below 0 ºC.
• Fault Messages
PUSH: Display Select
Amp Watts BatV
0.0 0.0 12.0
Amp-Hours
0 Ah
Total Amp-Hours
0 Ah
Mode: Charger
State: Bulk
Bulk Float
14.0V 13.4V
EQU EQU-T CYCLE
14.2V 1hr 28day
Heatsink BTS
25
o
C 25
o
C
PUSH: Display Select
PUSH: Display SelectPUSH: Display Select
PUSH: Display Select
PUSH: Display Select
PUSH: Display Select
