16 EB 2520 EN
Design and principle of operation
Table2: Dimensions in mm
Valve size DN15 DN20 DN25 DN32 DN40 DN50
Length L 130 150 160 180 200 230
Height H2
Forged steel 53 – 70 – 92 98
Other materials 44 72
Set point range
5to15mbar
Height H
Without balancing 325 370
With balancing 352 377
Actuator ØD=485mm,A=1200cm²
10to30mbar
Height H
Without balancing 318 366
With balancing 345 370
Actuator
ØD=380mm,
A=640cm²
ØD=485mm,
A=1200cm²
25to60mbar
Height H
Without balancing 318 366
With balancing 345 370
Actuator ØD=380mm,A=640cm²
50to200mbar
Height H
Without balancing 318 366
With balancing 345 370
Actuator ØD=285mm,A=320cm²
0.1to0.6bar
Height H
Without balancing 318 366
With balancing 345 370
Actuator ØD=285mm,A=320cm²
0.2to1bar
Height H
Without balancing 318 366
With balancing 345 370
Actuator ØD=225mm,A=160cm²
0.8to2.5bar
Height H
Without balancing 330 365
With balancing 356 369
Actuator ØD=170mm,A=80cm²
2to5bar
Height H
Without balancing 333 368mm
With balancing 359 373mm
Actuator ØD=170mm,A=40cm²
4.5to10bar
Height H
Without balancing 437 485
With balancing 463 489
Actuator ØD=170mm,A=40cm²
