Annex
15 Annex
15.1 Tightening torques, lubricants and tools
uAB0100 for tools, tightening torques and lubricants
15.2 Accessories
Tabelle15-1.1: Wedge between valve shaft, shaft adapter and actuator
NPS 1 1½ 2 3 4 6 8 10 12
DN 25 40 50 80 100 150 200 250 300
Square drive
connection
WidthacrossatsSWforvalveshaftsquaredrive
12 12 12 12 19 19 27 27 27
Item numbers of wedges (accessories)
F05 VK14 7316 7348 – – – – – –
F07 VK17 7317 7239 – – – – –
F10 VK22 – – 7732 7240 – – –
F12 VK27 – – – – 7241 7755
F14 VK36 – – – – 7770 7243
F16 VK46 – – – – 9613
15.3 Spare parts
01 Support shaft
02 Yoke
03 Bottom ange
05 Body
07 Segmented ball
08 Arrow plate
09 Nameplate
10 Spring
11 Key drive
12 Valve shaft
15 Packing gland
17 Bearing bushing
18 Bearing bushing
20 Washer
21 Seat ring
22 O-ring seal
23 Washer
24 Sliding washer
25 Support ring
26 Metal tubular seal
27 Spring-loaded gasket
30 Retainer
35 Bushing
40 V-ring packing
46 Gasket
47 Spring
49 Spacer
55 Round-head grooved
pin
60 Screw
65 Stud
70 Retaining screw
75 Nut
80 Washer
85 Screw
88 O-ring seal
90 Gasket
